Week 46: Decision Trees, Ensemble methods and Random Forests#
Morten Hjorth-Jensen, Department of Physics, University of Oslo and Department of Physics and Astronomy and National Superconducting Cyclotron Laboratory, Michigan State University
Date: Week 46, November 11-15
Plan for week 46#
Lab sessions on Tuesday and Wednesday.
Work on and discussions of project 3
Material for the lecture on Monday November 11, 2024.
Basics of decision trees, classification and regression algorithms and ensemble models
Readings and Videos:
a. Lecture notes at CompPhysics/MachineLearning
b. Video on Decision trees at https://www.youtube.com/watch?v=RmajweUFKvM&ab_channel=Simplilearn
c. Decision Trees: Rashcka et al chapter 3 pages 86-98, and chapter 7 on Ensemble methods, Voting and Bagging and Gradient Boosting. See also lecture from STK-IN4300, lecture 7 at https://www.uio.no/studier/emner/matnat/math/STK-IN4300/h20/slides/lecture_7.pdf.
Decision trees, overarching aims#
We start here with the most basic algorithm, the so-called decision tree. With this basic algorithm we can in turn build more complex networks, spanning from homogeneous and heterogenous forests (bagging, random forests and more) to one of the most popular supervised algorithms nowadays, the extreme gradient boosting, or just XGBoost. But let us start with the simplest possible ingredient.
Decision trees are supervised learning algorithms used for both, classification and regression tasks.
The main idea of decision trees is to find those descriptive features which contain the most information regarding the target feature and then split the dataset along the values of these features such that the target feature values for the resulting underlying datasets are as pure as possible.
The descriptive features which reproduce best the target/output features are normally said to be the most informative ones. The process of finding the most informative feature is done until we accomplish a stopping criteria where we then finally end up in so called leaf nodes.
Basics of a tree#
A decision tree is typically divided into a root node, the interior nodes, and the final leaf nodes or just leaves. These entities are then connected by so-called branches.
The leaf nodes contain the predictions we will make for new query instances presented to our trained model. This is possible since the model has learned the underlying structure of the training data and hence can, given some assumptions, make predictions about the target feature value (class) of unseen query instances.
A typical Decision Tree with its pertinent Jargon, Classification Problem#
Figure 1:
This tree was produced using the Wisconsin cancer data (discussed here as well, see code examples below) using Scikit-Learn’s decision tree classifier. Here we have used the so-called gini index (see below) to split the various branches.
General Features#
The overarching approach to decision trees is a top-down approach.
A leaf provides the classification of a given instance.
A node specifies a test of some attribute of the instance.
A branch corresponds to a possible values of an attribute.
An instance is classified by starting at the root node of the tree, testing the attribute specified by this node, then moving down the tree branch corresponding to the value of the attribute in the given example.
This process is then repeated for the subtree rooted at the new node.
How do we set it up?#
In simplified terms, the process of training a decision tree and predicting the target features of query instances is as follows:
Present a dataset containing of a number of training instances characterized by a number of descriptive features and a target feature
Train the decision tree model by continuously splitting the target feature along the values of the descriptive features using a measure of information gain during the training process
Grow the tree until we accomplish a stopping criteria create leaf nodes which represent the predictions we want to make for new query instances
Show query instances to the tree and run down the tree until we arrive at leaf nodes
Then we are essentially done!
Decision trees and Regression#
%matplotlib inline
import numpy as np
import matplotlib.pyplot as plt
from sklearn.preprocessing import PolynomialFeatures
from sklearn.linear_model import LinearRegression
steps=250
distance=0
x=0
distance_list=[]
steps_list=[]
while x<steps:
distance+=np.random.randint(-1,2)
distance_list.append(distance)
x+=1
steps_list.append(x)
plt.plot(steps_list,distance_list, color='green', label="Random Walk Data")
steps_list=np.asarray(steps_list)
distance_list=np.asarray(distance_list)
X=steps_list[:,np.newaxis]
#Polynomial fits
#Degree 2
poly_features=PolynomialFeatures(degree=2, include_bias=False)
X_poly=poly_features.fit_transform(X)
lin_reg=LinearRegression()
poly_fit=lin_reg.fit(X_poly,distance_list)
b=lin_reg.coef_
c=lin_reg.intercept_
print ("2nd degree coefficients:")
print ("zero power: ",c)
print ("first power: ", b[0])
print ("second power: ",b[1])
z = np.arange(0, steps, .01)
z_mod=b[1]*z**2+b[0]*z+c
fit_mod=b[1]*X**2+b[0]*X+c
plt.plot(z, z_mod, color='r', label="2nd Degree Fit")
plt.title("Polynomial Regression")
plt.xlabel("Steps")
plt.ylabel("Distance")
#Degree 10
poly_features10=PolynomialFeatures(degree=10, include_bias=False)
X_poly10=poly_features10.fit_transform(X)
poly_fit10=lin_reg.fit(X_poly10,distance_list)
y_plot=poly_fit10.predict(X_poly10)
plt.plot(X, y_plot, color='black', label="10th Degree Fit")
plt.legend()
plt.show()
#Decision Tree Regression
from sklearn.tree import DecisionTreeRegressor
regr_1=DecisionTreeRegressor(max_depth=2)
regr_2=DecisionTreeRegressor(max_depth=5)
regr_3=DecisionTreeRegressor(max_depth=11)
regr_1.fit(X, distance_list)
regr_2.fit(X, distance_list)
regr_3.fit(X, distance_list)
X_test = np.arange(0.0, steps, 0.01)[:, np.newaxis]
y_1 = regr_1.predict(X_test)
y_2 = regr_2.predict(X_test)
y_3=regr_3.predict(X_test)
# Plot the results
plt.figure()
plt.scatter(X, distance_list, s=2.5, c="black", label="data")
plt.plot(X_test, y_1, color="red",
label="max_depth=2", linewidth=2)
plt.plot(X_test, y_2, color="green", label="max_depth=5", linewidth=2)
plt.plot(X_test, y_3, color="m", label="max_depth=7", linewidth=2)
plt.xlabel("Data")
plt.ylabel("Darget")
plt.title("Decision Tree Regression")
plt.legend()
plt.show()
2nd degree coefficients:
zero power: 1.391131752817723
first power: 0.023929544236763082
second power: -0.00011233101388608391
Building a tree, regression#
There are mainly two steps
We split the predictor space (the set of possible values \(x_1,x_2,\dots, x_p\)) into \(J\) distinct and non-non-overlapping regions, \(R_1,R_2,\dots,R_J\).
For every observation that falls into the region \(R_j\) , we make the same prediction, which is simply the mean of the response values for the training observations in \(R_j\).
How do we construct the regions \(R_1,\dots,R_J\)? In theory, the regions could have any shape. However, we choose to divide the predictor space into high-dimensional rectangles, or boxes, for simplicity and for ease of interpretation of the resulting predictive model. The goal is to find boxes \(R_1,\dots,R_J\) that minimize the MSE, given by
where \(\overline{y}_{R_j}\) is the mean response for the training observations within box \(j\).
A top-down approach, recursive binary splitting#
Unfortunately, it is computationally infeasible to consider every possible partition of the feature space into \(J\) boxes. The common strategy is to take a top-down approach
The approach is top-down because it begins at the top of the tree (all observations belong to a single region) and then successively splits the predictor space; each split is indicated via two new branches further down on the tree. It is greedy because at each step of the tree-building process, the best split is made at that particular step, rather than looking ahead and picking a split that will lead to a better tree in some future step.
Making a tree#
In order to implement the recursive binary splitting we start by selecting the predictor \(x_j\) and a cutpoint \(s\) that splits the predictor space into two regions \(R_1\) and \(R_2\)
and
so that we obtain the lowest MSE, that is
which we want to minimize by considering all predictors \(x_1,x_2,\dots,x_p\). We consider also all possible values of \(s\) for each predictor. These values could be determined by randomly assigned numbers or by starting at the midpoint and then proceed till we find an optimal value.
For any \(j\) and \(s\), we define the pair of half-planes where \(\overline{y}_{R_1}\) is the mean response for the training observations in \(R_1(j,s)\), and \(\overline{y}_{R_2}\) is the mean response for the training observations in \(R_2(j,s)\).
Finding the values of \(j\) and \(s\) that minimize the above equation can be done quite quickly, especially when the number of features \(p\) is not too large.
Next, we repeat the process, looking for the best predictor and best cutpoint in order to split the data further so as to minimize the MSE within each of the resulting regions. However, this time, instead of splitting the entire predictor space, we split one of the two previously identified regions. We now have three regions. Again, we look to split one of these three regions further, so as to minimize the MSE. The process continues until a stopping criterion is reached; for instance, we may continue until no region contains more than five observations.
Pruning the tree#
The above procedure is rather straightforward, but leads often to overfitting and unnecessarily large and complicated trees. The basic idea is to grow a large tree \(T_0\) and then prune it back in order to obtain a subtree. A smaller tree with fewer splits (fewer regions) can lead to smaller variance and better interpretation at the cost of a little more bias.
The so-called Cost complexity pruning algorithm gives us a way to do just this. Rather than considering every possible subtree, we consider a sequence of trees indexed by a nonnegative tuning parameter \(\alpha\).
Read more at the following Scikit-Learn link on pruning.
Cost complexity pruning#
For each value of \(\alpha\) there corresponds a subtree \(T \in T_0\) such that
is as small as possible. Here \(\overline{T}\) is the number of terminal nodes of the tree \(T\) , \(R_m\) is the rectangle (i.e. the subset of predictor space) corresponding to the \(m\)-th terminal node.
The tuning parameter \(\alpha\) controls a trade-off between the subtree’s complexity and its fit to the training data. When \(\alpha = 0\), then the subtree \(T\) will simply equal \(T_0\), because then the above equation just measures the training error. However, as \(\alpha\) increases, there is a price to pay for having a tree with many terminal nodes. The above equation will tend to be minimized for a smaller subtree.
It turns out that as we increase \(\alpha\) from zero branches get pruned from the tree in a nested and predictable fashion, so obtaining the whole sequence of subtrees as a function of \(\alpha\) is easy. We can select a value of \(\alpha\) using a validation set or using cross-validation. We then return to the full data set and obtain the subtree corresponding to \(\alpha\).
Schematic Regression Procedure#
Building a Regression Tree.
Use recursive binary splitting to grow a large tree on the training data, stopping only when each terminal node has fewer than some minimum number of observations.
Apply cost complexity pruning to the large tree in order to obtain a sequence of best subtrees, as a function of \(\alpha\).
Use for example \(K\)-fold cross-validation to choose \(\alpha\). Divide the training observations into \(K\) folds. For each \(k=1,2,\dots,K\) we:
repeat steps 1 and 2 on all but the \(k\)-th fold of the training data.
Then we valuate the mean squared prediction error on the data in the left-out \(k\)-th fold, as a function of \(\alpha\).
Finally we average the results for each value of \(\alpha\), and pick \(\alpha\) to minimize the average error.
Return the subtree from Step 2 that corresponds to the chosen value of \(\alpha\).
A Classification Tree#
A classification tree is very similar to a regression tree, except that it is used to predict a qualitative response rather than a quantitative one. Recall that for a regression tree, the predicted response for an observation is given by the mean response of the training observations that belong to the same terminal node. In contrast, for a classification tree, we predict that each observation belongs to the most commonly occurring class of training observations in the region to which it belongs. In interpreting the results of a classification tree, we are often interested not only in the class prediction corresponding to a particular terminal node region, but also in the class proportions among the training observations that fall into that region.
Growing a classification tree#
The task of growing a classification tree is quite similar to the task of growing a regression tree. Just as in the regression setting, we use recursive binary splitting to grow a classification tree. However, in the classification setting, the MSE cannot be used as a criterion for making the binary splits. A natural alternative to MSE is the classification error rate. Since we plan to assign an observation in a given region to the most commonly occurring error rate class of training observations in that region, the classification error rate is simply the fraction of the training observations in that region that do not belong to the most common class.
When building a classification tree, either the Gini index or the entropy are typically used to evaluate the quality of a particular split, since these two approaches are more sensitive to node purity than is the classification error rate.
Classification tree, how to split nodes#
If our targets are the outcome of a classification process that takes for example \(k=1,2,\dots,K\) values, the only thing we need to think of is to set up the splitting criteria for each node.
We define a PDF \(p_{mk}\) that represents the number of observations of a class \(k\) in a region \(R_m\) with \(N_m\) observations. We represent this likelihood function in terms of the proportion \(I(y_i=k)\) of observations of this class in the region \(R_m\) as
We let \(p_{mk}\) represent the majority class of observations in region \(m\). The three most common ways of splitting a node are given by
Misclassification error
Gini index \(g\)
Information entropy or just entropy \(s\)
Visualizing the Tree, Classification#
import os
from sklearn.datasets import load_breast_cancer
from sklearn.tree import DecisionTreeClassifier
from sklearn.model_selection import train_test_split
from sklearn.metrics import confusion_matrix
from sklearn.tree import export_graphviz
from IPython.display import Image
from pydot import graph_from_dot_data
import pandas as pd
import numpy as np
cancer = load_breast_cancer()
X = pd.DataFrame(cancer.data, columns=cancer.feature_names)
print(X)
y = pd.Categorical.from_codes(cancer.target, cancer.target_names)
y = pd.get_dummies(y)
print(y)
X_train, X_test, y_train, y_test = train_test_split(X, y, random_state=1)
tree_clf = DecisionTreeClassifier(max_depth=5)
tree_clf.fit(X_train, y_train)
export_graphviz(
tree_clf,
out_file="DataFiles/cancer.dot",
feature_names=cancer.feature_names,
class_names=cancer.target_names,
rounded=True,
filled=True
)
cmd = 'dot -Tpng DataFiles/cancer.dot -o DataFiles/cancer.png'
os.system(cmd)
mean radius mean texture mean perimeter mean area mean smoothness \
0 17.99 10.38 122.80 1001.0 0.11840
1 20.57 17.77 132.90 1326.0 0.08474
2 19.69 21.25 130.00 1203.0 0.10960
3 11.42 20.38 77.58 386.1 0.14250
4 20.29 14.34 135.10 1297.0 0.10030
.. ... ... ... ... ...
564 21.56 22.39 142.00 1479.0 0.11100
565 20.13 28.25 131.20 1261.0 0.09780
566 16.60 28.08 108.30 858.1 0.08455
567 20.60 29.33 140.10 1265.0 0.11780
568 7.76 24.54 47.92 181.0 0.05263
mean compactness mean concavity mean concave points mean symmetry \
0 0.27760 0.30010 0.14710 0.2419
1 0.07864 0.08690 0.07017 0.1812
2 0.15990 0.19740 0.12790 0.2069
3 0.28390 0.24140 0.10520 0.2597
4 0.13280 0.19800 0.10430 0.1809
.. ... ... ... ...
564 0.11590 0.24390 0.13890 0.1726
565 0.10340 0.14400 0.09791 0.1752
566 0.10230 0.09251 0.05302 0.1590
567 0.27700 0.35140 0.15200 0.2397
568 0.04362 0.00000 0.00000 0.1587
mean fractal dimension ... worst radius worst texture \
0 0.07871 ... 25.380 17.33
1 0.05667 ... 24.990 23.41
2 0.05999 ... 23.570 25.53
3 0.09744 ... 14.910 26.50
4 0.05883 ... 22.540 16.67
.. ... ... ... ...
564 0.05623 ... 25.450 26.40
565 0.05533 ... 23.690 38.25
566 0.05648 ... 18.980 34.12
567 0.07016 ... 25.740 39.42
568 0.05884 ... 9.456 30.37
worst perimeter worst area worst smoothness worst compactness \
0 184.60 2019.0 0.16220 0.66560
1 158.80 1956.0 0.12380 0.18660
2 152.50 1709.0 0.14440 0.42450
3 98.87 567.7 0.20980 0.86630
4 152.20 1575.0 0.13740 0.20500
.. ... ... ... ...
564 166.10 2027.0 0.14100 0.21130
565 155.00 1731.0 0.11660 0.19220
566 126.70 1124.0 0.11390 0.30940
567 184.60 1821.0 0.16500 0.86810
568 59.16 268.6 0.08996 0.06444
worst concavity worst concave points worst symmetry \
0 0.7119 0.2654 0.4601
1 0.2416 0.1860 0.2750
2 0.4504 0.2430 0.3613
3 0.6869 0.2575 0.6638
4 0.4000 0.1625 0.2364
.. ... ... ...
564 0.4107 0.2216 0.2060
565 0.3215 0.1628 0.2572
566 0.3403 0.1418 0.2218
567 0.9387 0.2650 0.4087
568 0.0000 0.0000 0.2871
worst fractal dimension
0 0.11890
1 0.08902
2 0.08758
3 0.17300
4 0.07678
.. ...
564 0.07115
565 0.06637
566 0.07820
567 0.12400
568 0.07039
[569 rows x 30 columns]
malignant benign
0 True False
1 True False
2 True False
3 True False
4 True False
.. ... ...
564 True False
565 True False
566 True False
567 True False
568 False True
[569 rows x 2 columns]
0
Visualizing the Tree, The Moons#
# Common imports
import numpy as np
from sklearn.model_selection import train_test_split
from sklearn.tree import DecisionTreeClassifier
from sklearn.datasets import make_moons
from sklearn.tree import export_graphviz
from pydot import graph_from_dot_data
import pandas as pd
import os
np.random.seed(42)
X, y = make_moons(n_samples=100, noise=0.25, random_state=53)
X_train, X_test, y_train, y_test = train_test_split(X,y,random_state=0)
tree_clf = DecisionTreeClassifier(max_depth=5)
tree_clf.fit(X_train, y_train)
export_graphviz(
tree_clf,
out_file="DataFiles/moons.dot",
rounded=True,
filled=True
)
cmd = 'dot -Tpng DataFiles/moons.dot -o DataFiles/moons.png'
os.system(cmd)
0
Other ways of visualizing the trees#
Scikit-Learn has also another way to visualize the trees which is very useful, here with the Iris data.
from sklearn.datasets import load_iris
from sklearn import tree
X, y = load_iris(return_X_y=True)
tree_clf = tree.DecisionTreeClassifier()
tree_clf = tree_clf.fit(X, y)
# and then plot the tree
tree.plot_tree(tree_clf)
[Text(0.5, 0.9166666666666666, 'x[2] <= 2.45\ngini = 0.667\nsamples = 150\nvalue = [50, 50, 50]'),
Text(0.4230769230769231, 0.75, 'gini = 0.0\nsamples = 50\nvalue = [50, 0, 0]'),
Text(0.5769230769230769, 0.75, 'x[3] <= 1.75\ngini = 0.5\nsamples = 100\nvalue = [0, 50, 50]'),
Text(0.3076923076923077, 0.5833333333333334, 'x[2] <= 4.95\ngini = 0.168\nsamples = 54\nvalue = [0, 49, 5]'),
Text(0.15384615384615385, 0.4166666666666667, 'x[3] <= 1.65\ngini = 0.041\nsamples = 48\nvalue = [0, 47, 1]'),
Text(0.07692307692307693, 0.25, 'gini = 0.0\nsamples = 47\nvalue = [0, 47, 0]'),
Text(0.23076923076923078, 0.25, 'gini = 0.0\nsamples = 1\nvalue = [0, 0, 1]'),
Text(0.46153846153846156, 0.4166666666666667, 'x[3] <= 1.55\ngini = 0.444\nsamples = 6\nvalue = [0, 2, 4]'),
Text(0.38461538461538464, 0.25, 'gini = 0.0\nsamples = 3\nvalue = [0, 0, 3]'),
Text(0.5384615384615384, 0.25, 'x[2] <= 5.45\ngini = 0.444\nsamples = 3\nvalue = [0, 2, 1]'),
Text(0.46153846153846156, 0.08333333333333333, 'gini = 0.0\nsamples = 2\nvalue = [0, 2, 0]'),
Text(0.6153846153846154, 0.08333333333333333, 'gini = 0.0\nsamples = 1\nvalue = [0, 0, 1]'),
Text(0.8461538461538461, 0.5833333333333334, 'x[2] <= 4.85\ngini = 0.043\nsamples = 46\nvalue = [0, 1, 45]'),
Text(0.7692307692307693, 0.4166666666666667, 'x[1] <= 3.1\ngini = 0.444\nsamples = 3\nvalue = [0, 1, 2]'),
Text(0.6923076923076923, 0.25, 'gini = 0.0\nsamples = 2\nvalue = [0, 0, 2]'),
Text(0.8461538461538461, 0.25, 'gini = 0.0\nsamples = 1\nvalue = [0, 1, 0]'),
Text(0.9230769230769231, 0.4166666666666667, 'gini = 0.0\nsamples = 43\nvalue = [0, 0, 43]')]
Printing out as text#
Alternatively, the tree can also be exported in textual format with the function exporttext. This method doesn’t require the installation of external libraries and is more compact:
from sklearn.datasets import load_iris
from sklearn.tree import DecisionTreeClassifier
from sklearn.tree import export_text
iris = load_iris()
decision_tree = DecisionTreeClassifier(random_state=0, max_depth=2)
decision_tree = decision_tree.fit(iris.data, iris.target)
r = export_text(decision_tree, feature_names=iris['feature_names'])
print(r)
|--- petal width (cm) <= 0.80
| |--- class: 0
|--- petal width (cm) > 0.80
| |--- petal width (cm) <= 1.75
| | |--- class: 1
| |--- petal width (cm) > 1.75
| | |--- class: 2
Algorithms for Setting up Decision Trees#
Two algorithms stand out in the set up of decision trees:
The CART (Classification And Regression Tree) algorithm for both classification and regression
The ID3 algorithm based on the computation of the information gain for classification
We discuss both algorithms with applications here. The popular library Scikit-Learn uses the CART algorithm. For classification problems you can use either the gini index or the entropy to split a tree in two branches.
The CART algorithm for Classification#
For classification, the CART algorithm splits the data set in two subsets using a single feature \(k\) and a threshold \(t_k\). This could be for example a threshold set by a number below a certain circumference of a malign tumor.
How do we find these two quantities? We search for the pair \((k,t_k)\) that produces the purest subset using for example the gini factor \(G\). The cost function it tries to minimize is then
where \(G_{\mathrm{left/right}}\) measures the impurity of the left/right subset and \(m_{\mathrm{left/right}}\) is the number of instances in the left/right subset
Once it has successfully split the training set in two, it splits the subsets using the same logic, then the subsubsets and so on, recursively. It stops recursing once it reaches the maximum depth (defined by the \(max\_depth\) hyperparameter), or if it cannot find a split that will reduce impurity. A few other hyperparameters control additional stopping conditions such as the \(min\_samples\_split\), \(min\_samples\_leaf\), \(min\_weight\_fraction\_leaf\), and \(max\_leaf\_nodes\).
The CART algorithm for Regression#
The CART algorithm for regression works is similar to the one for classification except that instead of trying to split the training set in a way that minimizes say the gini or entropy impurity, it now tries to split the training set in a way that minimizes our well-known mean-squared error (MSE). The cost function is now
Here the MSE for a specific node is defined as
with
the mean value of all observations in a specific node.
Without any regularization, the regression task for decision trees, just like for classification tasks, is prone to overfitting.
Why binary splits?#
It is custom to split to a tree uising binary splits. The reason is that multiway splits fragment the data too quickly, leaving insufficient data at the next level down. Multiway splits can be achieved by a series of binary split and this is normally preferred.
Computing a Tree using the Gini Index#
Consider the following example with attributes/features and two possible outcomes (classes) for each attribute. Assume we wish to find some correlations between the average grade of a student as function of the number of hours studied and hours slept. We want also to correlate the grade in a given course with the general trend, whether the students recently has gotten grades below average or above.
We have three features/attributes
Trend of average grades before present course, classified as either below or above the average grade of the whole class
The number of hours studies, classified again as either higher (more than 3 hours per day) or lower . Here we have used a standard for one \(ECTS\) which is scaled to 25-30 hours of work for a semester which lasts 18 weeks, with 15 weeks of lectures and 3 weeks for exams, assuming a total of 30 ECTS per semester.
The number of hours slept as high for more than \(8\) hours and below for less than 8 hours of sleep, classified again as either high or low
The final grade whether it is above or below average
The Table#
| Grade Trend | Hours slept | Hours Studied | Grade |
|---|---|---|---|
| Above | Low | High | Above |
| Below | High | Low | Below |
| Above | Low | High | Above |
| Above | High | High | Above |
| Below | Low | High | Below |
| Above | Low | Low | Below |
| Below | High | High | Below |
| Below | Low | High | Below |
| Above | Low | Low | Below |
| Above | High | High | Above |
Computing the various Gini Indices#
In computations we will translate all classes into numbers. Being these binary classes, they can easily be split into ones and zeros.
Gini index for Average trend.
Computing the various Gini Indices, Hours slept#
Gini index for hour slept.
Computing the various Gini Indices, Hours studied#
Gini index for hour studied.
See handwritten notes November 3
For final tree, see the above handwritten notes
A possible code using Scikit-Learn#
# Common imports
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from sklearn.tree import DecisionTreeClassifier
from sklearn.model_selection import train_test_split
from sklearn.tree import export_graphviz
from sklearn.preprocessing import StandardScaler, OneHotEncoder
from sklearn.compose import ColumnTransformer
from IPython.display import Image
from pydot import graph_from_dot_data
import os
# Where to save the figures and data files
PROJECT_ROOT_DIR = "Results"
FIGURE_ID = "Results/FigureFiles"
DATA_ID = "DataFiles/"
if not os.path.exists(PROJECT_ROOT_DIR):
os.mkdir(PROJECT_ROOT_DIR)
if not os.path.exists(FIGURE_ID):
os.makedirs(FIGURE_ID)
if not os.path.exists(DATA_ID):
os.makedirs(DATA_ID)
def image_path(fig_id):
return os.path.join(FIGURE_ID, fig_id)
def data_path(dat_id):
return os.path.join(DATA_ID, dat_id)
def save_fig(fig_id):
plt.savefig(image_path(fig_id) + ".png", format='png')
infile = open(data_path("grades.csv"),'r')
# Read the experimental data with Pandas
from IPython.display import display
grades = pd.read_csv(infile)
grades = pd.DataFrame(grades)
display(grades)
# Features and targets
X = grades.loc[:, grades.columns != 'Grade'].values
y = grades.loc[:, grades.columns == 'Grade'].values
print(X)
# Then do a Classification tree
tree_clf = DecisionTreeClassifier(max_depth=2)
tree_clf.fit(X, y)
print("Train set accuracy with Decision Tree: {:.2f}".format(tree_clf.score(X,y)))
#transfer to a decision tree graph
export_graphviz(
tree_clf,
out_file="DataFiles/grade.dot",
rounded=True,
filled=True
)
cmd = 'dot -Tpng DataFiles/grade.dot -o DataFiles/grades.png'
os.system(cmd)
| Grade Trend | Hours slept | Hours Studied | Grade | |
|---|---|---|---|---|
| 0 | 1 | 0 | 1 | 1 |
| 1 | 0 | 1 | 0 | 0 |
| 2 | 1 | 0 | 1 | 1 |
| 3 | 1 | 1 | 1 | 1 |
| 4 | 0 | 0 | 1 | 0 |
| 5 | 1 | 0 | 0 | 0 |
| 6 | 0 | 1 | 1 | 0 |
| 7 | 0 | 0 | 1 | 0 |
| 8 | 1 | 0 | 0 | 0 |
| 9 | 1 | 1 | 1 | 1 |
[[1 0 1]
[0 1 0]
[1 0 1]
[1 1 1]
[0 0 1]
[1 0 0]
[0 1 1]
[0 0 1]
[1 0 0]
[1 1 1]]
Train set accuracy with Decision Tree: 1.00
0
Further example: Computing the Gini index#
The next example we will look at is a classical one in many Machine Learning applications. Based on various meteorological features, we have several so-called attributes which decide whether we at the end will do some outdoor activity like skiing, going for a bike ride etc etc. The table here contains the feautures outlook, temperature, humidity and wind. The target or output is whether we ride (True=1) or whether we do something else that day (False=0). The attributes for each feature are then sunny, overcast and rain for the outlook, hot, cold and mild for temperature, high and normal for humidity and weak and strong for wind.
The table here summarizes the various attributes and
| Day | Outlook | Temperature | Humidity | Wind | Ride |
|---|---|---|---|---|---|
| 1 | Sunny | Hot | High | Weak | 0 |
| 2 | Sunny | Hot | High | Strong | 1 |
| 3 | Overcast | Hot | High | Weak | 1 |
| 4 | Rain | Mild | High | Weak | 1 |
| 5 | Rain | Cool | Normal | Weak | 1 |
| 6 | Rain | Cool | Normal | Strong | 0 |
| 7 | Overcast | Cool | Normal | Strong | 1 |
| 8 | Sunny | Mild | High | Weak | 0 |
| 9 | Sunny | Cool | Normal | Weak | 1 |
| 10 | Rain | Mild | Normal | Weak | 1 |
| 11 | Sunny | Mild | Normal | Strong | 1 |
| 12 | Overcast | Mild | High | Strong | 1 |
| 13 | Overcast | Hot | Normal | Weak | 1 |
| 14 | Rain | Mild | High | Strong | 0 |
Simple Python Code to read in Data and perform Classification#
# Common imports
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
from sklearn.tree import DecisionTreeClassifier
from sklearn.model_selection import train_test_split
from sklearn.tree import export_graphviz
from sklearn.preprocessing import StandardScaler, OneHotEncoder
from sklearn.compose import ColumnTransformer
from IPython.display import Image
from pydot import graph_from_dot_data
import os
# Where to save the figures and data files
PROJECT_ROOT_DIR = "Results"
FIGURE_ID = "Results/FigureFiles"
DATA_ID = "DataFiles/"
if not os.path.exists(PROJECT_ROOT_DIR):
os.mkdir(PROJECT_ROOT_DIR)
if not os.path.exists(FIGURE_ID):
os.makedirs(FIGURE_ID)
if not os.path.exists(DATA_ID):
os.makedirs(DATA_ID)
def image_path(fig_id):
return os.path.join(FIGURE_ID, fig_id)
def data_path(dat_id):
return os.path.join(DATA_ID, dat_id)
def save_fig(fig_id):
plt.savefig(image_path(fig_id) + ".png", format='png')
infile = open(data_path("rideclass.csv"),'r')
# Read the experimental data with Pandas
from IPython.display import display
ridedata = pd.read_csv(infile,names = ('Outlook','Temperature','Humidity','Wind','Ride'))
ridedata = pd.DataFrame(ridedata)
# Features and targets
X = ridedata.loc[:, ridedata.columns != 'Ride'].values
y = ridedata.loc[:, ridedata.columns == 'Ride'].values
# Create the encoder.
encoder = OneHotEncoder(handle_unknown="ignore")
# Assume for simplicity all features are categorical.
encoder.fit(X)
# Apply the encoder.
X = encoder.transform(X)
print(X)
# Then do a Classification tree
tree_clf = DecisionTreeClassifier(max_depth=2)
tree_clf.fit(X, y)
print("Train set accuracy with Decision Tree: {:.2f}".format(tree_clf.score(X,y)))
#transfer to a decision tree graph
export_graphviz(
tree_clf,
out_file="DataFiles/ride.dot",
rounded=True,
filled=True
)
cmd = 'dot -Tpng DataFiles/cancer.dot -o DataFiles/cancer.png'
os.system(cmd)
(0, 0) 1.0
(0, 7) 1.0
(0, 9) 1.0
(0, 13) 1.0
(1, 3) 1.0
(1, 5) 1.0
(1, 8) 1.0
(1, 12) 1.0
(2, 3) 1.0
(2, 5) 1.0
(2, 8) 1.0
(2, 11) 1.0
(3, 1) 1.0
(3, 5) 1.0
(3, 8) 1.0
(3, 12) 1.0
(4, 2) 1.0
(4, 6) 1.0
(4, 8) 1.0
(4, 12) 1.0
(5, 2) 1.0
(5, 4) 1.0
(5, 10) 1.0
(5, 12) 1.0
(6, 2) 1.0
: :
(8, 12) 1.0
(9, 3) 1.0
(9, 4) 1.0
(9, 10) 1.0
(9, 12) 1.0
(10, 2) 1.0
(10, 6) 1.0
(10, 10) 1.0
(10, 12) 1.0
(11, 3) 1.0
(11, 6) 1.0
(11, 10) 1.0
(11, 11) 1.0
(12, 1) 1.0
(12, 6) 1.0
(12, 8) 1.0
(12, 11) 1.0
(13, 1) 1.0
(13, 5) 1.0
(13, 10) 1.0
(13, 12) 1.0
(14, 2) 1.0
(14, 6) 1.0
(14, 8) 1.0
(14, 11) 1.0
Train set accuracy with Decision Tree: 0.73
0
Computing the Gini Factor#
The above functions (gini, entropy and misclassification error) are important components of the so-called CART algorithm. We will discuss this algorithm below after we have discussed the information gain algorithm ID3.
In the example here we have converted all our attributes into numerical values \(0,1,2\) etc.
# Split a dataset based on an attribute and an attribute value
def test_split(index, value, dataset):
left, right = list(), list()
for row in dataset:
if row[index] < value:
left.append(row)
else:
right.append(row)
return left, right
# Calculate the Gini index for a split dataset
def gini_index(groups, classes):
# count all samples at split point
n_instances = float(sum([len(group) for group in groups]))
# sum weighted Gini index for each group
gini = 0.0
for group in groups:
size = float(len(group))
# avoid divide by zero
if size == 0:
continue
score = 0.0
# score the group based on the score for each class
for class_val in classes:
p = [row[-1] for row in group].count(class_val) / size
score += p * p
# weight the group score by its relative size
gini += (1.0 - score) * (size / n_instances)
return gini
# Select the best split point for a dataset
def get_split(dataset):
class_values = list(set(row[-1] for row in dataset))
b_index, b_value, b_score, b_groups = 999, 999, 999, None
for index in range(len(dataset[0])-1):
for row in dataset:
groups = test_split(index, row[index], dataset)
gini = gini_index(groups, class_values)
print('X%d < %.3f Gini=%.3f' % ((index+1), row[index], gini))
if gini < b_score:
b_index, b_value, b_score, b_groups = index, row[index], gini, groups
return {'index':b_index, 'value':b_value, 'groups':b_groups}
dataset = [[0,0,0,0,0],
[0,0,0,1,1],
[1,0,0,0,1],
[2,1,0,0,1],
[2,2,1,0,1],
[2,2,1,1,0],
[1,2,1,1,1],
[0,1,0,0,0],
[0,2,1,0,1],
[2,1,1,0,1],
[0,1,1,1,1],
[1,1,0,1,1],
[1,0,1,0,1],
[2,1,0,1,0]]
split = get_split(dataset)
print('Split: [X%d < %.3f]' % ((split['index']+1), split['value']))
X1 < 0.000 Gini=0.408
X1 < 0.000 Gini=0.408
X1 < 1.000 Gini=0.394
X1 < 2.000 Gini=0.394
X1 < 2.000 Gini=0.394
X1 < 2.000 Gini=0.394
X1 < 1.000 Gini=0.394
X1 < 0.000 Gini=0.408
X1 < 0.000 Gini=0.408
X1 < 2.000 Gini=0.394
X1 < 0.000 Gini=0.408
X1 < 1.000 Gini=0.394
X1 < 1.000 Gini=0.394
X1 < 2.000 Gini=0.394
X2 < 0.000 Gini=0.408
X2 < 0.000 Gini=0.408
X2 < 0.000 Gini=0.408
X2 < 1.000 Gini=0.407
X2 < 2.000 Gini=0.407
X2 < 2.000 Gini=0.407
X2 < 2.000 Gini=0.407
X2 < 1.000 Gini=0.407
X2 < 2.000 Gini=0.407
X2 < 1.000 Gini=0.407
X2 < 1.000 Gini=0.407
X2 < 1.000 Gini=0.407
X2 < 0.000 Gini=0.408
X2 < 1.000 Gini=0.407
X3 < 0.000 Gini=0.408
X3 < 0.000 Gini=0.408
X3 < 0.000 Gini=0.408
X3 < 0.000 Gini=0.408
X3 < 1.000 Gini=0.367
X3 < 1.000 Gini=0.367
X3 < 1.000 Gini=0.367
X3 < 0.000 Gini=0.408
X3 < 1.000 Gini=0.367
X3 < 1.000 Gini=0.367
X3 < 1.000 Gini=0.367
X3 < 0.000 Gini=0.408
X3 < 1.000 Gini=0.367
X3 < 0.000 Gini=0.408
X4 < 0.000 Gini=0.408
X4 < 1.000 Gini=0.405
X4 < 0.000 Gini=0.408
X4 < 0.000 Gini=0.408
X4 < 0.000 Gini=0.408
X4 < 1.000 Gini=0.405
X4 < 1.000 Gini=0.405
X4 < 0.000 Gini=0.408
X4 < 0.000 Gini=0.408
X4 < 0.000 Gini=0.408
X4 < 1.000 Gini=0.405
X4 < 1.000 Gini=0.405
X4 < 0.000 Gini=0.408
X4 < 1.000 Gini=0.405
Split: [X3 < 1.000]
Regression trees#
# Quadratic training set + noise
np.random.seed(42)
m = 200
X = np.random.rand(m, 1)
y = 4 * (X - 0.5) ** 2
y = y + np.random.randn(m, 1) / 10
from sklearn.tree import DecisionTreeRegressor
tree_reg = DecisionTreeRegressor(max_depth=2, random_state=42)
tree_reg.fit(X, y)
DecisionTreeRegressor(max_depth=2, random_state=42)In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
DecisionTreeRegressor(max_depth=2, random_state=42)
Final regressor code#
from sklearn.tree import DecisionTreeRegressor
tree_reg1 = DecisionTreeRegressor(random_state=42, max_depth=2)
tree_reg2 = DecisionTreeRegressor(random_state=42, max_depth=3)
tree_reg1.fit(X, y)
tree_reg2.fit(X, y)
def plot_regression_predictions(tree_reg, X, y, axes=[0, 1, -0.2, 1], ylabel="$y$"):
x1 = np.linspace(axes[0], axes[1], 500).reshape(-1, 1)
y_pred = tree_reg.predict(x1)
plt.axis(axes)
plt.xlabel("$x_1$", fontsize=18)
if ylabel:
plt.ylabel(ylabel, fontsize=18, rotation=0)
plt.plot(X, y, "b.")
plt.plot(x1, y_pred, "r.-", linewidth=2, label=r"$\hat{y}$")
plt.figure(figsize=(11, 4))
plt.subplot(121)
plot_regression_predictions(tree_reg1, X, y)
for split, style in ((0.1973, "k-"), (0.0917, "k--"), (0.7718, "k--")):
plt.plot([split, split], [-0.2, 1], style, linewidth=2)
plt.text(0.21, 0.65, "Depth=0", fontsize=15)
plt.text(0.01, 0.2, "Depth=1", fontsize=13)
plt.text(0.65, 0.8, "Depth=1", fontsize=13)
plt.legend(loc="upper center", fontsize=18)
plt.title("max_depth=2", fontsize=14)
plt.subplot(122)
plot_regression_predictions(tree_reg2, X, y, ylabel=None)
for split, style in ((0.1973, "k-"), (0.0917, "k--"), (0.7718, "k--")):
plt.plot([split, split], [-0.2, 1], style, linewidth=2)
for split in (0.0458, 0.1298, 0.2873, 0.9040):
plt.plot([split, split], [-0.2, 1], "k:", linewidth=1)
plt.text(0.3, 0.5, "Depth=2", fontsize=13)
plt.title("max_depth=3", fontsize=14)
plt.show()
tree_reg1 = DecisionTreeRegressor(random_state=42)
tree_reg2 = DecisionTreeRegressor(random_state=42, min_samples_leaf=10)
tree_reg1.fit(X, y)
tree_reg2.fit(X, y)
x1 = np.linspace(0, 1, 500).reshape(-1, 1)
y_pred1 = tree_reg1.predict(x1)
y_pred2 = tree_reg2.predict(x1)
plt.figure(figsize=(11, 4))
plt.subplot(121)
plt.plot(X, y, "b.")
plt.plot(x1, y_pred1, "r.-", linewidth=2, label=r"$\hat{y}$")
plt.axis([0, 1, -0.2, 1.1])
plt.xlabel("$x_1$", fontsize=18)
plt.ylabel("$y$", fontsize=18, rotation=0)
plt.legend(loc="upper center", fontsize=18)
plt.title("No restrictions", fontsize=14)
plt.subplot(122)
plt.plot(X, y, "b.")
plt.plot(x1, y_pred2, "r.-", linewidth=2, label=r"$\hat{y}$")
plt.axis([0, 1, -0.2, 1.1])
plt.xlabel("$x_1$", fontsize=18)
plt.title("min_samples_leaf={}".format(tree_reg2.min_samples_leaf), fontsize=14)
plt.show()
Pros and cons of trees, pros#
White box, easy to interpret model. Some people believe that decision trees more closely mirror human decision-making than do the regression and classification approaches discussed earlier (think of support vector machines)
Trees are very easy to explain to people. In fact, they are even easier to explain than linear regression!
No feature normalization needed
Tree models can handle both continuous and categorical data (Classification and Regression Trees)
Can model nonlinear relationships
Can model interactions between the different descriptive features
Trees can be displayed graphically, and are easily interpreted even by a non-expert (especially if they are small)
Disadvantages#
Unfortunately, trees generally do not have the same level of predictive accuracy as some of the other regression and classification approaches
If continuous features are used the tree may become quite large and hence less interpretable
Decision trees are prone to overfit the training data and hence do not well generalize the data if no stopping criteria or improvements like pruning, boosting or bagging are implemented
Small changes in the data may lead to a completely different tree. This issue can be addressed by using ensemble methods like bagging, boosting or random forests
Unbalanced datasets where some target feature values occur much more frequently than others may lead to biased trees since the frequently occurring feature values are preferred over the less frequently occurring ones.
If the number of features is relatively large (high dimensional) and the number of instances is relatively low, the tree might overfit the data
Features with many levels may be preferred over features with less levels since for them it is more easy to split the dataset such that the sub datasets only contain pure target feature values. This issue can be addressed by preferring for instance the information gain ratio as splitting criteria over information gain
However, by aggregating many decision trees, using methods like bagging, random forests, and boosting, the predictive performance of trees can be substantially improved.
Ensemble Methods: From a Single Tree to Many Trees and Extreme Boosting, Meet the Jungle of Methods#
As stated above and seen in many of the examples discussed here about a single decision tree, we often end up overfitting our training data. This normally means that we have a high variance. Can we reduce the variance of a statistical learning method?
This leads us to a set of different methods that can combine different machine learning algorithms or just use one of them to construct forests and jungles of trees, homogeneous ones or heterogenous ones. These methods are recognized by different names which we will try to explain here. These are
Voting classifiers
Bagging and Pasting
Random forests
Boosting methods, from adaptive to Extreme Gradient Boosting (XGBoost)
We discuss these methods here.
An Overview of Ensemble Methods#
Figure 1:
Why Voting?#
The idea behind boosting, and voting as well can be phrased as follows: Can a group of people somehow arrive at highly reasoned decisions, despite the weak judgement of the individual members?
The aim is to create a good classifier by combining several weak classifiers. A weak classifier is a classifier which is able to produce results that are only slightly better than guessing at random.
The basic approach is to apply repeatedly (in boosting this is done in an iterative way) a weak classifier to modifications of the data. In voting we simply apply the law of large numbers while in boosting we give more weight to misclassified data in each iteration.
Decision trees play an important role as our weak classifier. They serve as the basic method.
Tossing coins#
The simplest case is a so-called voting ensemble. To illustrate this, think of yourself tossing coins with a biased outcome of 51 per cent for heads and 49% for tails. With only few tosses, you may not clearly see this distribution for heads and tails. However, after some thousands of tosses, there will be a clear majority of heads. With 2000 tosses you should see approximately 1020 heads and 980 tails.
We can then state that the outcome is a clear majority of heads. If you do this ten thousand times, it is easy to see that there is a 97% likelihood of a majority of heads.
Another example would be to collect all polls before an election. Different polls may show different likelihoods for a candidate winning with say a majority of the popular vote. The majority vote would then consist in many polls indicating that this candidate will actually win.
The example here shows how we can implement the coin tossing case, clealry demostrating that after some tosses we see the law of large numbers kicking in.
Standard imports first#
# Common imports
from IPython.display import Image
from pydot import graph_from_dot_data
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
from sklearn.tree import DecisionTreeClassifier
from sklearn.model_selection import train_test_split
from sklearn.tree import export_graphviz
from sklearn.preprocessing import StandardScaler, OneHotEncoder
from sklearn.compose import ColumnTransformer
from IPython.display import Image
from pydot import graph_from_dot_data
import os
# Where to save the figures and data files
PROJECT_ROOT_DIR = "Results"
FIGURE_ID = "Results/FigureFiles"
DATA_ID = "DataFiles/"
if not os.path.exists(PROJECT_ROOT_DIR):
os.mkdir(PROJECT_ROOT_DIR)
if not os.path.exists(FIGURE_ID):
os.makedirs(FIGURE_ID)
if not os.path.exists(DATA_ID):
os.makedirs(DATA_ID)
def image_path(fig_id):
return os.path.join(FIGURE_ID, fig_id)
def data_path(dat_id):
return os.path.join(DATA_ID, dat_id)
def save_fig(fig_id):
plt.savefig(image_path(fig_id) + ".png", format='png')
Simple Voting Example, head or tail#
# Common imports
import numpy as np
import matplotlib
import matplotlib.pyplot as plt
from matplotlib.colors import ListedColormap
plt.rcParams['axes.labelsize'] = 14
plt.rcParams['xtick.labelsize'] = 12
plt.rcParams['ytick.labelsize'] = 12
heads_proba = 0.51
coin_tosses = (np.random.rand(10000, 10) < heads_proba).astype(np.int32)
cumulative_heads_ratio = np.cumsum(coin_tosses, axis=0) / np.arange(1, 10001).reshape(-1, 1)
plt.figure(figsize=(8,3.5))
plt.plot(cumulative_heads_ratio)
plt.plot([0, 10000], [0.51, 0.51], "k--", linewidth=2, label="51%")
plt.plot([0, 10000], [0.5, 0.5], "k-", label="50%")
plt.xlabel("Number of coin tosses")
plt.ylabel("Heads ratio")
plt.legend(loc="lower right")
plt.axis([0, 10000, 0.42, 0.58])
save_fig("votingsimple")
plt.show()
Using the Voting Classifier#
We can use the voting classifier on other data sets, here the exciting binary case of two distinct objects using the make moons functionality of Scikit-Learn.
from sklearn.model_selection import train_test_split
from sklearn.datasets import make_moons
X, y = make_moons(n_samples=500, noise=0.30, random_state=42)
X_train, X_test, y_train, y_test = train_test_split(X, y, random_state=42)
from sklearn.ensemble import RandomForestClassifier
from sklearn.ensemble import VotingClassifier
from sklearn.linear_model import LogisticRegression
from sklearn.svm import SVC
log_clf = LogisticRegression(solver="liblinear", random_state=42)
rnd_clf = RandomForestClassifier(n_estimators=10, random_state=42)
svm_clf = SVC(gamma="auto", random_state=42)
voting_clf = VotingClassifier(
estimators=[('lr', log_clf), ('rf', rnd_clf), ('svc', svm_clf)],
voting='hard')
voting_clf.fit(X_train, y_train)
from sklearn.metrics import accuracy_score
for clf in (log_clf, rnd_clf, svm_clf, voting_clf):
clf.fit(X_train, y_train)
y_pred = clf.predict(X_test)
print(clf.__class__.__name__, accuracy_score(y_test, y_pred))
log_clf = LogisticRegression(solver="liblinear", random_state=42)
rnd_clf = RandomForestClassifier(n_estimators=10, random_state=42)
svm_clf = SVC(gamma="auto", probability=True, random_state=42)
voting_clf = VotingClassifier(
estimators=[('lr', log_clf), ('rf', rnd_clf), ('svc', svm_clf)],
voting='soft')
voting_clf.fit(X_train, y_train)
from sklearn.metrics import accuracy_score
for clf in (log_clf, rnd_clf, svm_clf, voting_clf):
clf.fit(X_train, y_train)
y_pred = clf.predict(X_test)
print(clf.__class__.__name__, accuracy_score(y_test, y_pred))
LogisticRegression 0.864
RandomForestClassifier 0.872
SVC 0.888
VotingClassifier 0.896
LogisticRegression 0.864
RandomForestClassifier 0.872
SVC 0.888
VotingClassifier 0.912
Voting and Bagging#
from sklearn.model_selection import train_test_split
from sklearn.datasets import make_moons
X, y = make_moons(n_samples=500, noise=0.30, random_state=42)
X_train, X_test, y_train, y_test = train_test_split(X, y, random_state=42)
from sklearn.ensemble import RandomForestClassifier
from sklearn.ensemble import VotingClassifier
from sklearn.linear_model import LogisticRegression
from sklearn.svm import SVC
log_clf = LogisticRegression(random_state=42)
rnd_clf = RandomForestClassifier(random_state=42)
svm_clf = SVC(random_state=42)
voting_clf = VotingClassifier(
estimators=[('lr', log_clf), ('rf', rnd_clf), ('svc', svm_clf)],
voting='hard')
voting_clf.fit(X_train, y_train)
VotingClassifier(estimators=[('lr', LogisticRegression(random_state=42)),
('rf', RandomForestClassifier(random_state=42)),
('svc', SVC(random_state=42))])In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook. On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
VotingClassifier(estimators=[('lr', LogisticRegression(random_state=42)),
('rf', RandomForestClassifier(random_state=42)),
('svc', SVC(random_state=42))])LogisticRegression(random_state=42)
RandomForestClassifier(random_state=42)
SVC(random_state=42)
from sklearn.metrics import accuracy_score
for clf in (log_clf, rnd_clf, svm_clf, voting_clf):
clf.fit(X_train, y_train)
y_pred = clf.predict(X_test)
print(clf.__class__.__name__, accuracy_score(y_test, y_pred))
LogisticRegression 0.864
RandomForestClassifier 0.896
SVC 0.896
VotingClassifier 0.912
log_clf = LogisticRegression(random_state=42)
rnd_clf = RandomForestClassifier(random_state=42)
svm_clf = SVC(probability=True, random_state=42)
voting_clf = VotingClassifier(
estimators=[('lr', log_clf), ('rf', rnd_clf), ('svc', svm_clf)],
voting='soft')
voting_clf.fit(X_train, y_train)
VotingClassifier(estimators=[('lr', LogisticRegression(random_state=42)),
('rf', RandomForestClassifier(random_state=42)),
('svc', SVC(probability=True, random_state=42))],
voting='soft')In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook. On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.
VotingClassifier(estimators=[('lr', LogisticRegression(random_state=42)),
('rf', RandomForestClassifier(random_state=42)),
('svc', SVC(probability=True, random_state=42))],
voting='soft')LogisticRegression(random_state=42)
RandomForestClassifier(random_state=42)
SVC(probability=True, random_state=42)
from sklearn.metrics import accuracy_score
for clf in (log_clf, rnd_clf, svm_clf, voting_clf):
clf.fit(X_train, y_train)
y_pred = clf.predict(X_test)
print(clf.__class__.__name__, accuracy_score(y_test, y_pred))
LogisticRegression 0.864
RandomForestClassifier 0.896
SVC 0.896
VotingClassifier 0.92
Bagging#
The plain decision trees suffer from high variance. This means that if we split the training data into two parts at random, and fit a decision tree to both halves, the results that we get could be quite different. In contrast, a procedure with low variance will yield similar results if applied repeatedly to distinct data sets; linear regression tends to have low variance, if the ratio of \(n\) to \(p\) is moderately large.
Bootstrap aggregation, or just bagging, is a general-purpose procedure for reducing the variance of a statistical learning method.
More bagging#
Bagging typically results in improved accuracy over prediction using a single tree. Unfortunately, however, it can be difficult to interpret the resulting model. Recall that one of the advantages of decision trees is the attractive and easily interpreted diagram that results.
However, when we bag a large number of trees, it is no longer possible to represent the resulting statistical learning procedure using a single tree, and it is no longer clear which variables are most important to the procedure. Thus, bagging improves prediction accuracy at the expense of interpretability. Although the collection of bagged trees is much more difficult to interpret than a single tree, one can obtain an overall summary of the importance of each predictor using the MSE (for bagging regression trees) or the Gini index (for bagging classification trees). In the case of bagging regression trees, we can record the total amount that the MSE is decreased due to splits over a given predictor, averaged over all \(B\) possible trees. A large value indicates an important predictor. Similarly, in the context of bagging classification trees, we can add up the total amount that the Gini index is decreased by splits over a given predictor, averaged over all \(B\) trees.
Making your own Bootstrap: Changing the Level of the Decision Tree#
Let us bring up our good old boostrap example from the linear regression lectures. We change the linerar regression algorithm with a decision tree wth different depths and perform a bootstrap aggregate (in this case we perform as many bootstraps as data points \(n\)).
import matplotlib.pyplot as plt
import numpy as np
from sklearn.model_selection import train_test_split
from sklearn.pipeline import make_pipeline
from sklearn.utils import resample
from sklearn.tree import DecisionTreeRegressor
n = 100
n_boostraps = 100
maxdepth = 8
# Make data set.
x = np.linspace(-3, 3, n).reshape(-1, 1)
y = np.exp(-x**2) + 1.5 * np.exp(-(x-2)**2)+ np.random.normal(0, 0.1, x.shape)
error = np.zeros(maxdepth)
bias = np.zeros(maxdepth)
variance = np.zeros(maxdepth)
polydegree = np.zeros(maxdepth)
X_train, X_test, y_train, y_test = train_test_split(x, y, test_size=0.2)
from sklearn.preprocessing import StandardScaler
scaler = StandardScaler()
scaler.fit(X_train)
X_train_scaled = scaler.transform(X_train)
X_test_scaled = scaler.transform(X_test)
# we produce a simple tree first as benchmark
simpletree = DecisionTreeRegressor(max_depth=3)
simpletree.fit(X_train_scaled, y_train)
simpleprediction = simpletree.predict(X_test_scaled)
for degree in range(1,maxdepth):
model = DecisionTreeRegressor(max_depth=degree)
y_pred = np.empty((y_test.shape[0], n_boostraps))
for i in range(n_boostraps):
x_, y_ = resample(X_train_scaled, y_train)
model.fit(x_, y_)
y_pred[:, i] = model.predict(X_test_scaled)#.ravel()
polydegree[degree] = degree
error[degree] = np.mean( np.mean((y_test - y_pred)**2, axis=1, keepdims=True) )
bias[degree] = np.mean( (y_test - np.mean(y_pred, axis=1, keepdims=True))**2 )
variance[degree] = np.mean( np.var(y_pred, axis=1, keepdims=True) )
print('Polynomial degree:', degree)
print('Error:', error[degree])
print('Bias^2:', bias[degree])
print('Var:', variance[degree])
print('{} >= {} + {} = {}'.format(error[degree], bias[degree], variance[degree], bias[degree]+variance[degree]))
mse_simpletree= np.mean( np.mean((y_test - simpleprediction)**2))
print("Simple tree:",mse_simpletree)
plt.xlim(1,maxdepth)
plt.plot(polydegree, error, label='MSE')
plt.plot(polydegree, bias, label='bias')
plt.plot(polydegree, variance, label='Variance')
plt.legend()
save_fig("baggingboot")
plt.show()
Polynomial degree: 1
Error: 0.06380941468319971
Bias^2: 0.05160313473529168
Var: 0.01220627994790804
0.06380941468319971 >= 0.05160313473529168 + 0.01220627994790804 = 0.06380941468319971
Polynomial degree: 2
Error: 0.043464037468677004
Bias^2: 0.02659851591375224
Var: 0.01686552155492476
0.043464037468677004 >= 0.02659851591375224 + 0.01686552155492476 = 0.043464037468677
Polynomial degree: 3
Error: 0.020716391693769383
Bias^2: 0.01159033914386312
Var: 0.00912605254990626
0.020716391693769383 >= 0.01159033914386312 + 0.00912605254990626 = 0.02071639169376938
Polynomial degree: 4
Error: 0.02063627410934057
Bias^2: 0.0117496656370668
Var: 0.008886608472273775
0.02063627410934057 >= 0.0117496656370668 + 0.008886608472273775 = 0.020636274109340574
Polynomial degree: 5
Error: 0.02087627881701288
Bias^2: 0.01349183949256158
Var: 0.007384439324451296
0.02087627881701288 >= 0.01349183949256158 + 0.007384439324451296 = 0.020876278817012876
Polynomial degree: 6
Error: 0.02069601123831537
Bias^2: 0.013918526350129823
Var: 0.0067774848881855445
0.02069601123831537 >= 0.013918526350129823 + 0.0067774848881855445 = 0.020696011238315368
Polynomial degree: 7
Error: 0.022964339924731444
Bias^2: 0.01550381208433455
Var: 0.007460527840396904
0.022964339924731444 >= 0.01550381208433455 + 0.007460527840396904 = 0.022964339924731455
Simple tree: 0.5148389267750961
Random forests#
Random forests provide an improvement over bagged trees by way of a small tweak that decorrelates the trees.
As in bagging, we build a number of decision trees on bootstrapped training samples. But when building these decision trees, each time a split in a tree is considered, a random sample of \(m\) predictors is chosen as split candidates from the full set of \(p\) predictors. The split is allowed to use only one of those \(m\) predictors.
A fresh sample of \(m\) predictors is taken at each split, and typically we choose
In building a random forest, at each split in the tree, the algorithm is not even allowed to consider a majority of the available predictors.
The reason for this is rather clever. Suppose that there is one very strong predictor in the data set, along with a number of other moderately strong predictors. Then in the collection of bagged variable importance random forest trees, most or all of the trees will use this strong predictor in the top split. Consequently, all of the bagged trees will look quite similar to each other. Hence the predictions from the bagged trees will be highly correlated. Unfortunately, averaging many highly correlated quantities does not lead to as large of a reduction in variance as averaging many uncorrelated quantities. In particular, this means that bagging will not lead to a substantial reduction in variance over a single tree in this setting.
Random Forest Algorithm#
The algorithm described here can be applied to both classification and regression problems.
We will grow of forest of say \(B\) trees.
For \(b=1:B\)
Draw a bootstrap sample from the training data organized in our \(\boldsymbol{X}\) matrix.
We grow then a random forest tree \(T_b\) based on the bootstrapped data by repeating the steps outlined till we reach the maximum node size is reached
we select \(m \le p\) variables at random from the \(p\) predictors/features
pick the best split point among the \(m\) features using for example the CART algorithm and create a new node
split the node into daughter nodes
Output then the ensemble of trees \(\{T_b\}_1^{B}\) and make predictions for either a regression type of problem or a classification type of problem.
Random Forests Compared with other Methods on the Cancer Data#
import matplotlib.pyplot as plt
import numpy as np
from sklearn.model_selection import train_test_split
from sklearn.datasets import load_breast_cancer
from sklearn.svm import SVC
from sklearn.linear_model import LogisticRegression
from sklearn.tree import DecisionTreeClassifier
from sklearn.ensemble import BaggingClassifier
# Load the data
cancer = load_breast_cancer()
X_train, X_test, y_train, y_test = train_test_split(cancer.data,cancer.target,random_state=0)
print(X_train.shape)
print(X_test.shape)
#define methods
# Logistic Regression
logreg = LogisticRegression(solver='lbfgs')
# Support vector machine
svm = SVC(gamma='auto', C=100)
# Decision Trees
deep_tree_clf = DecisionTreeClassifier(max_depth=None)
#Scale the data
from sklearn.preprocessing import StandardScaler
scaler = StandardScaler()
scaler.fit(X_train)
X_train_scaled = scaler.transform(X_train)
X_test_scaled = scaler.transform(X_test)
# Logistic Regression
logreg.fit(X_train_scaled, y_train)
print("Test set accuracy Logistic Regression with scaled data: {:.2f}".format(logreg.score(X_test_scaled,y_test)))
# Support Vector Machine
svm.fit(X_train_scaled, y_train)
print("Test set accuracy SVM with scaled data: {:.2f}".format(logreg.score(X_test_scaled,y_test)))
# Decision Trees
deep_tree_clf.fit(X_train_scaled, y_train)
print("Test set accuracy with Decision Trees and scaled data: {:.2f}".format(deep_tree_clf.score(X_test_scaled,y_test)))
from sklearn.ensemble import RandomForestClassifier
from sklearn.preprocessing import LabelEncoder
from sklearn.model_selection import cross_validate
# Data set not specificied
#Instantiate the model with 500 trees and entropy as splitting criteria
Random_Forest_model = RandomForestClassifier(n_estimators=500,criterion="entropy")
Random_Forest_model.fit(X_train_scaled, y_train)
#Cross validation
accuracy = cross_validate(Random_Forest_model,X_test_scaled,y_test,cv=10)['test_score']
print(accuracy)
print("Test set accuracy with Random Forests and scaled data: {:.2f}".format(Random_Forest_model.score(X_test_scaled,y_test)))
import scikitplot as skplt
y_pred = Random_Forest_model.predict(X_test_scaled)
skplt.metrics.plot_confusion_matrix(y_test, y_pred, normalize=True)
plt.show()
y_probas = Random_Forest_model.predict_proba(X_test_scaled)
skplt.metrics.plot_roc(y_test, y_probas)
plt.show()
skplt.metrics.plot_cumulative_gain(y_test, y_probas)
plt.show()
(426, 30)
(143, 30)
Test set accuracy Logistic Regression with scaled data: 0.96
Test set accuracy SVM with scaled data: 0.96
Test set accuracy with Decision Trees and scaled data: 0.87
[0.93333333 0.73333333 0.93333333 1. 1. 0.92857143
1. 0.92857143 0.92857143 0.92857143]
Test set accuracy with Random Forests and scaled data: 0.98
Recall that the cumulative gains curve shows the percentage of the overall number of cases in a given category gained by targeting a percentage of the total number of cases.
Similarly, the receiver operating characteristic curve, or ROC curve, displays the diagnostic ability of a binary classifier system as its discrimination threshold is varied. It plots the true positive rate against the false positive rate.
Compare Bagging on Trees with Random Forests#
bag_clf = BaggingClassifier(
DecisionTreeClassifier(splitter="random", max_leaf_nodes=16, random_state=42),
n_estimators=500, max_samples=1.0, bootstrap=True, n_jobs=-1, random_state=42)
bag_clf.fit(X_train, y_train)
y_pred = bag_clf.predict(X_test)
from sklearn.ensemble import RandomForestClassifier
rnd_clf = RandomForestClassifier(n_estimators=500, max_leaf_nodes=16, n_jobs=-1, random_state=42)
rnd_clf.fit(X_train, y_train)
y_pred_rf = rnd_clf.predict(X_test)
np.sum(y_pred == y_pred_rf) / len(y_pred)
0.9790209790209791
Boosting, a Bird’s Eye View#
The basic idea is to combine weak classifiers in order to create a good classifier. With a weak classifier we often intend a classifier which produces results which are only slightly better than we would get by random guesses.
This is done by applying in an iterative way a weak (or a standard classifier like decision trees) to modify the data. In each iteration we emphasize those observations which are misclassified by weighting them with a factor.
What is boosting? Additive Modelling/Iterative Fitting#
Boosting is a way of fitting an additive expansion in a set of elementary basis functions like for example some simple polynomials. Assume for example that we have a function
where \(\beta_m\) are the expansion parameters to be determined in a minimization process and \(b(x;\gamma_m)\) are some simple functions of the multivariable parameter \(x\) which is characterized by the parameters \(\gamma_m\).
As an example, consider the Sigmoid function we used in logistic regression. In that case, we can translate the function \(b(x;\gamma_m)\) into the Sigmoid function
where \(t=\gamma_0+\gamma_1 x\) and the parameters \(\gamma_0\) and \(\gamma_1\) were determined by the Logistic Regression fitting algorithm.
As another example, consider the cost function we defined for linear regression
In this case the function \(f(x)\) was replaced by the design matrix \(\boldsymbol{X}\) and the unknown linear regression parameters \(\boldsymbol{\beta}\), that is \(\boldsymbol{f}=\boldsymbol{X}\boldsymbol{\beta}\). In linear regression we can simply invert a matrix and obtain the parameters \(\beta\) by
In iterative fitting or additive modeling, we minimize the cost function with respect to the parameters \(\beta_m\) and \(\gamma_m\).
Iterative Fitting, Regression and Squared-error Cost Function#
The way we proceed is as follows (here we specialize to the squared-error cost function)
Establish a cost function, here \(C(\boldsymbol{y},\boldsymbol{f}) = \frac{1}{n} \sum_{i=0}^{n-1}(y_i-f_M(x_i))^2\) with \(f_M(x) = \sum_{i=1}^M \beta_m b(x;\gamma_m)\).
Initialize with a guess \(f_0(x)\). It could be one or even zero or some random numbers.
For \(m=1:M\)
a. minimize \(\sum_{i=0}^{n-1}(y_i-f_{m-1}(x_i)-\beta b(x;\gamma))^2\) wrt \(\gamma\) and \(\beta\)
b. This gives the optimal values \(\beta_m\) and \(\gamma_m\)
c. Determine then the new values \(f_m(x)=f_{m-1}(x) +\beta_m b(x;\gamma_m)\)
We could use any of the algorithms we have discussed till now. If we use trees, \(\gamma\) parameterizes the split variables and split points at the internal nodes, and the predictions at the terminal nodes.
Squared-Error Example and Iterative Fitting#
To better understand what happens, let us develop the steps for the iterative fitting using the above squared error function.
For simplicity we assume also that our functions \(b(x;\gamma)=1+\gamma x\).
This means that for every iteration \(m\), we need to optimize
We start our iteration by simply setting \(f_0(x)=0\). Taking the derivatives with respect to \(\beta\) and \(\gamma\) we obtain
and
We can then rewrite these equations as (defining \(\boldsymbol{w}=\boldsymbol{e}+\gamma \boldsymbol{x})\) with \(\boldsymbol{e}\) being the unit vector)
which gives us \(\beta = \boldsymbol{w}^T\boldsymbol{y}/(\boldsymbol{w}^T\boldsymbol{w})\). Similarly we have
which leads to \(\gamma =(\boldsymbol{x}^T\boldsymbol{y}-\beta\boldsymbol{x}^T\boldsymbol{e})/(\beta\boldsymbol{x}^T\boldsymbol{x})\). Inserting for \(\beta\) gives us an equation for \(\gamma\). This is a non-linear equation in the unknown \(\gamma\) and has to be solved numerically.
The solution to these two equations gives us in turn \(\beta_1\) and \(\gamma_1\) leading to the new expression for \(f_1(x)\) as \(f_1(x) = \beta_1(1+\gamma_1x)\). Doing this \(M\) times results in our final estimate for the function \(f\).
Iterative Fitting, Classification and AdaBoost#
Let us consider a binary classification problem with two outcomes \(y_i \in \{-1,1\}\) and \(i=0,1,2,\dots,n-1\) as our set of observations. We define a classification function \(G(x)\) which produces a prediction taking one or the other of the two values \(\{-1,1\}\).
The error rate of the training sample is then
The iterative procedure starts with defining a weak classifier whose error rate is barely better than random guessing. The iterative procedure in boosting is to sequentially apply a weak classification algorithm to repeatedly modified versions of the data producing a sequence of weak classifiers \(G_m(x)\).
Here we will express our function \(f(x)\) in terms of \(G(x)\). That is
will be a function of
Adaptive Boosting, AdaBoost#
In our iterative procedure we define thus
The simplest possible cost function which leads (also simple from a computational point of view) to the AdaBoost algorithm is the exponential cost/loss function defined as
We optimize \(\beta\) and \(G\) for each value of \(m=1:M\) as we did in the regression case. This is normally done in two steps. Let us however first rewrite the cost function as
where we have defined \(w_i^m= \exp{(-y_if_{m-1}(x_i))}\).
Building up AdaBoost#
First, for any \(\beta > 0\), we optimize \(G\) by setting
which is the classifier that minimizes the weighted error rate in predicting \(y\).
We can do this by rewriting
which can be rewritten as
which leads to
where we have redefined the error as
which leads to an update of
This leads to the new weights
Adaptive boosting: AdaBoost, Basic Algorithm#
The algorithm here is rather straightforward. Assume that our weak classifier is a decision tree and we consider a binary set of outputs with \(y_i \in \{-1,1\}\) and \(i=0,1,2,\dots,n-1\) as our set of observations. Our design matrix is given in terms of the feature/predictor vectors \(\boldsymbol{X}=[\boldsymbol{x}_0\boldsymbol{x}_1\dots\boldsymbol{x}_{p-1}]\). Finally, we define also a classifier determined by our data via a function \(G(x)\). This function tells us how well we are able to classify our outputs/targets \(\boldsymbol{y}\).
We have already defined the misclassification error \(\mathrm{err}\) as
where the function \(I()\) is one if we misclassify and zero if we classify correctly.
Basic Steps of AdaBoost#
With the above definitions we are now ready to set up the algorithm for AdaBoost. The basic idea is to set up weights which will be used to scale the correctly classified and the misclassified cases.
We start by initializing all weights to \(w_i = 1/n\), with \(i=0,1,2,\dots n-1\). It is easy to see that we must have \(\sum_{i=0}^{n-1}w_i = 1\).
We rewrite the misclassification error as
Then we start looping over all attempts at classifying, namely we start an iterative process for \(m=1:M\), where \(M\) is the final number of classifications. Our given classifier could for example be a plain decision tree.
a. Fit then a given classifier to the training set using the weights \(w_i\).
b. Compute then \(\mathrm{err}\) and figure out which events are classified properly and which are classified wrongly.
c. Define a quantity \(\alpha_{m} = \log{(1-\mathrm{\overline{err}}_m)/\mathrm{\overline{err}}_m}\)
d. Set the new weights to \(w_i = w_i\times \exp{(\alpha_m I(y_i\ne G(x_i)}\).
Compute the new classifier \(G(x)= \sum_{i=0}^{n-1}\alpha_m I(y_i\ne G(x_i)\).
For the iterations with \(m \le 2\) the weights are modified individually at each steps. The observations which were misclassified at iteration \(m-1\) have a weight which is larger than those which were classified properly. As this proceeds, the observations which were difficult to classifiy correctly are given a larger influence. Each new classification step \(m\) is then forced to concentrate on those observations that are missed in the previous iterations.
AdaBoost Examples#
Using Scikit-Learn it is easy to apply the adaptive boosting algorithm, as done here.
from sklearn.ensemble import AdaBoostClassifier
ada_clf = AdaBoostClassifier(
DecisionTreeClassifier(max_depth=1), n_estimators=200,
algorithm="SAMME.R", learning_rate=0.5, random_state=42)
ada_clf.fit(X_train, y_train)
from sklearn.ensemble import AdaBoostClassifier
ada_clf = AdaBoostClassifier(
DecisionTreeClassifier(max_depth=1), n_estimators=200,
algorithm="SAMME.R", learning_rate=0.5, random_state=42)
ada_clf.fit(X_train_scaled, y_train)
y_pred = ada_clf.predict(X_test_scaled)
skplt.metrics.plot_confusion_matrix(y_test, y_pred, normalize=True)
plt.show()
y_probas = ada_clf.predict_proba(X_test_scaled)
skplt.metrics.plot_roc(y_test, y_probas)
plt.show()
skplt.metrics.plot_cumulative_gain(y_test, y_probas)
plt.show()
